Viewing Segment From and To Points

Some property values, such as address fields, are defined with reference to a segment's end points. One end point is considered the From point, and one end point is considered the To point.

Select the segment for which you want to view the From and To end points.
Click Map > Properties, or click the Properties button:

The Properties dialog box shows information for the current selection.
Do one or more of the following steps:
- To identify the segment From point, click the Show "From" Point button in the Properties dialog box:

  A hand pointing to the right shows the segment From point.
- To identify the segment To point, click the Show "To" Point button in the Properties dialog box:
  A hand pointing to the left shows the segment To point.
